Docker Cheatsheet

Checkout detailed article on Dev.to

1. Introduction to Docker

What is Docker?

• Docker is an open-source platform that automates the deployment, scaling, and management of applications by using containerization technology. Containers are lightweight, portable, and consistent environments that contain everything needed to run a piece of software, including the code, runtime, system tools, libraries, and settings.

Key Concepts

• Docker Engine: The core component of Docker, responsible for running containers.
• Image: A lightweight, standalone, and executable software package that includes everything needed to run an application.
• Container: A runtime instance of a Docker image that shares the host system's kernel.
• Dockerfile: A script containing a series of commands to assemble a Docker image.
• Registry: A storage and distribution system for Docker images, such as Docker Hub.
• Docker Compose: A tool for defining and running multi-container Docker applications using a YAML file.

---

2. Installing Docker

Install Docker on Linux

• Install Docker Engine:

  sudo apt-get update
  sudo apt-get install docker-ce docker-ce-cli containerd.io

• Start Docker Service:

  sudo systemctl start docker
  sudo systemctl enable docker

Install Docker on macOS

• Install Docker Desktop:
  • Download and install Docker Desktop from Docker's official website.

Install Docker on Windows

• Install Docker Desktop:
  • Download and install Docker Desktop from Docker's official website.

---

3. Basic Docker Operations

Working with Docker Images

• Search for an Image:

  docker search nginx

• Pull an Image from Docker Hub:

  docker pull nginx

• List All Images:

  docker images

• Remove an Image:

  docker rmi nginx

Working with Docker Containers

• Run a Container:

  docker run -d -p 80:80 --name mynginx nginx

• List Running Containers:

  docker ps

• List All Containers (including stopped):

  docker ps -a

• Stop a Running Container:

  docker stop mynginx

• Remove a Container:

  docker rm mynginx

Docker Networks

• List All Networks:

  docker network ls

• Create a New Network:

  docker network create mynetwork

• Connect a Container to a Network:

  docker network connect mynetwork mynginx

• Disconnect a Container from a Network:

  docker network disconnect mynetwork mynginx

---

4. Building Docker Images

Dockerfile Basics

• Sample Dockerfile:

  # Use an official Node.js runtime as a parent image
  FROM node:14

  # Set the working directory in the container
  WORKDIR /app

  # Copy the current directory contents into the container at /app
  COPY . /app

  # Install any needed packages specified in package.json
  RUN npm install

  # Make port 8080 available to the world outside this container
  EXPOSE 8080

  # Define environment variable
  ENV NODE_ENV production

  # Run app.js using node
  CMD ["node", "app.js"]

Building an Image from a Dockerfile

• Build the Image:

  docker build -t mynodeapp .

Managing Image Tags

• Tag an Image:

  docker tag mynodeapp myrepo/mynodeapp:v1.0

• Push an Image to Docker Hub:

  docker push myrepo/mynodeapp:v1.0

---

5. Docker Compose

Introduction to Docker Compose

• Docker Compose is a tool for defining and running multi-container Docker applications. You use a YAML file to configure your application's services, and then use a single command to create and start all the services.

Sample docker-compose.yml File

version: '3'
services:
  web:
    image: nginx
    ports:
      - "8080:80"
  db:
    image: mysql:5.7
    environment:
      MYSQL_ROOT_PASSWORD: example

Docker Compose Commands

• Start Services:

  docker-compose up

• Stop Services:

  docker-compose down

• Scale Services:

  docker-compose up --scale web=3

Managing Volumes with Docker Compose

• Defining Volumes:

  services:
    web:
      image: nginx
      volumes:
        - ./webdata:/usr/share/nginx/html

---

6. Docker Volumes and Storage

Understanding Docker Volumes

• Volumes are the preferred mechanism for persisting data generated and used by Docker containers.

Managing Volumes

• Create a Volume:

  docker volume create myvolume

• List All Volumes:

  docker volume ls

• Inspect a Volume:

  docker volume inspect myvolume

• Remove a Volume:

  docker volume rm myvolume

Mounting Volumes

• Mount a Volume to a Container:

  docker run -d -p 80:80 --name mynginx -v myvolume:/usr/share/nginx/html nginx

Bind Mounts

• Use a Bind Mount:

  docker run -d -p 80:80 --name mynginx -v /path/to/local/dir:/usr/share/nginx/html nginx

---

7. Docker Networking

Networking Modes

• Bridge Network: The default network driver, which allows containers to communicate on the same host.
• Host Network: Removes network isolation between the container and the Docker host.
• Overlay Network: Enables networking between multiple Docker hosts in a swarm.

Working with Networks

• Create a User-Defined Bridge Network:

  docker network create mynetwork

• Run a Container in a Network:

  docker run -d --name mynginx --network=mynetwork nginx

• Inspect a Network:

  docker network inspect mynetwork

DNS in Docker

• Docker containers can resolve each other's hostnames to IP addresses by using the embedded DNS server.

---

8. Docker Security

Securing Docker

• Least Privileged User: Always run containers as a non-root user.

  FROM nginx
  USER www-data

• Use Trusted Images: Use official images or images from trusted sources.

• Keep Docker Updated: Regularly update Docker to the latest version to benefit from security patches.

Docker Content Trust

• Enable Docker Content Trust (DCT):

  export DOCKER_CONTENT_TRUST=1

Managing Secrets

• Create a Secret in Docker Swarm:

  echo "mysecretpassword" | docker secret create my_secret -

• Use a Secret in a Service:

  docker service create --name myservice --secret my_secret nginx

Securing Docker Daemon

• Use TLS to Secure Docker API:
  • Generate TLS certificates and configure the Docker daemon to use them for secure communication.

Limiting Container Resources

• Limit Memory:

  docker run -d --name mynginx --memory="256m" nginx

• Limit CPU:

  docker run -d --name mynginx --cpus="1.0" nginx

---

9. Advanced Docker Features

Docker Swarm

• Initialize a Swarm:

  docker swarm init

• Join a Swarm:

  docker swarm join --token SWMTKN-1-xxxx

• Deploy a Stack:

  docker stack deploy -c docker-compose.yml mystack

Multi-Stage Builds

• Example of a Multi-Stage Dockerfile:

  # First Stage
  FROM golang:1.16 as builder
  WORKDIR /app
  COPY . .
  RUN go build -o myapp

  # Second Stage
  FROM alpine:latest
  WORKDIR /app
  COPY --from=builder /app/myapp .
  CMD ["./myapp"]

Docker Plugins

• List Installed Plugins:

  docker plugin ls

• **Install a Plugin

**:

docker plugin install vieux/sshfs

Docker Daemon Configuration

• Customizing Docker Daemon:

  • Edit the /etc/docker/daemon.json file to configure the Docker daemon.

  {
    "log-driver": "json-file",
    "log-level": "warn",
    "storage-driver": "overlay2"
  }

• Reload Daemon Configuration:

  sudo systemctl reload docker

---

10. Monitoring and Logging

Docker Logs

• View Container Logs:

  docker logs mynginx

• Follow Logs:

  docker logs -f mynginx

Monitoring Containers

• Inspect Resource Usage:

  docker stats mynginx

• Docker Events:

  • Monitor Docker events in real-time.

  docker events

Integrating with Monitoring Tools

• Prometheus and Grafana: Use cAdvisor and Prometheus Node Exporter to monitor Docker containers.

  docker run -d --name=cadvisor --volume=/:/rootfs:ro --volume=/var/run:/var/run:ro --volume=/sys:/sys:ro --volume=/var/lib/docker/:/var/lib/docker:ro --volume=/dev/disk/:/dev/disk:ro --publish=8080:8080 google/cadvisor:latest

---

11. Docker Best Practices

Dockerfile Best Practices

• Minimize Image Size: Use multi-stage builds and slim base images.
• Leverage Build Cache: Organize Dockerfile instructions to maximize the use of cache layers.
• Use .dockerignore: Exclude unnecessary files from the build context using a .dockerignore file.

Container Management Best Practices

• Immutable Infrastructure: Treat containers as immutable, replace rather than modify running containers.
• Keep Containers Stateless: Design containers to be stateless, with external data persistence.
• Log to STDOUT/STDERR: Ensure containers log to STDOUT/STDERR for easier aggregation and analysis.

Security Best Practices

• Regularly Scan Images: Use tools like trivy to scan images for vulnerabilities.

• Use Namespaces: Use namespaces to isolate container resources and enhance security.

• Limit Capabilities: Drop unnecessary capabilities from containers.

  docker run --cap-drop=ALL --cap-add=NET_BIND_SERVICE nginx

---

12. Troubleshooting Docker

Common Issues

• Container Exits Immediately:

  • Check the Docker logs for errors.

  docker logs <container_id>

• Image Build Fails:

  • Debug using the --no-cache option to rebuild the image without cache.

  docker build --no-cache -t myimage .

• Networking Issues:

  • Verify network settings and connectivity.

  docker network inspect <network_name>

Useful Docker Commands for Troubleshooting

• Inspect a Container:

  docker inspect <container_id>

• Enter a Running Container:

  docker exec -it <container_id> /bin/bash

• Check Resource Usage:

  docker stats

---

13. References

Official Documentation

• Docker Documentation

Community Resources

• Docker Hub
• Docker GitHub Repository
• Docker Forums
