Miru

Important

Development is done on Codeberg with a mirror in GitHub

A Wayland-native screen magnifier and cursor spotlight tool for streamers, built for Wayland compositors supporting the required wlroots protocols. Miru is primarily developed and tested on Niri.

Inspired by boomer, but for Wayland — written in C, keybind-driven, no GUI, no mouse-required config.

See Roadmap for the full picture.

Important

Miru currently requires both wlr-layer-shell-unstable-v1 and wlr-screencopy-unstable-v1. Compositors that do not expose these protocols are not currently supported.

In particular, GNOME (Mutter) and KDE Plasma (KWin) are not supported at this time.

Note

miru devlogs on YouTube https://youtube.com/playlist?list=PLZraydlsV2t0&si=jystH8Ik1UjDVu5t

Demo

Table of contents

• What it does
• Why
• Performance
• A note on global hotkeys
• Requirements
• Installing
• Building
• Running
• Man pages
• Configuration
• Project structure
• Roadmap
• Similar tools
• License
• Contributing

What it does

• Magnifier mode — press a key, the screen freezes into a zoomed-in fullscreen view centered on your cursor (or the last known pointer position from a previous session in the same daemon run). Move the mouse to pan, scroll or press +/- to adjust zoom, use arrow keys or WASD to pan by keyboard, press Esc (or the toggle key again) to exit. Like boomer, but native Wayland.

  While active:

  • Tab toggles Cursor Highlight — darkening everything except a soft-edged circle that follows the real pointer (absolute tracking), even when zoomed. Configurable via [spotlight]. Radius can be adjusted live with Shift+Plus/Minus or Ctrl+scroll. Entry/exit of the highlight is animated (spotlight.animation_speed).
  • Shift+A toggles Annotate mode — pan freezes and you can draw presentation shapes on the frozen frame (arrows, rectangles, lines, ellipse and circle). Defaults (tool, colors, thickness, text size) are configurable under [annotate]. See controls below.
  • Shift+H or ? toggles an on-screen help panel listing the current keybinds (Esc closes help first, then exits the magnifier).
  • Shift+E exports the current view to a .bmp file which is created at $HOME/Pictures/miru/ (Check out test_export.bmp)

  Cursor Highlight, annotations, export, and help only work inside an active Magnifier session; the desktop underneath stays frozen/grabbed while the overlay is on. Built and working now.

• Loupe Mode: miructl loupe freezes the screen the same way as miructl toggle, then lets you drag a rectangle over an area. After release, only the selected region is zoomed in a fixed-size window that follows the cursor; the rest of the frame stays at 1x. The selection shape is configurable ([loupe] shape: "rectangle", "ellipse" or "circle". Scroll to change loupe zoom. Toggle again (or quit) to exit. Separate from the above Magnifier Mode. Requires a separate compositor keybind.

• Spotlight mode — a fully independent, click-through overlay that darkens the whole screen except a cursor-tracking circle, while you keep working normally underneath — no freeze, no input grab, usable during normal desktop work rather than only inside a Magnifier session. This is a different, harder problem than Cursor Highlight above: it needs cursor tracking without stealing pointer/keyboard focus, which Cursor Highlight sidesteps entirely by already owning input while Magnifier is active. Work In Progress. (Mode is implemented, but cursor follow through is a WIP)

Why

Most screen magnifiers either don't exist for Wayland, or route through XWayland with visible artifacts and no compositor integration. Miru uses Wayland protocols directly, currently relying on wlr-layer-shell for its overlay and wlr-screencopy for screen capture. The overlay itself is rendered with OpenGL ES 2 via EGL.

Performance

Because there's no continuous re-capture while the overlay is inactive (see Setting up a keybind below for why), miru-daemon sits completely idle — blocked in poll() waiting for either a Wayland event or a toggle command — for as long as you're not actively using it. In practice this means ~0% CPU usage at rest:

A note on global hotkeys

Miru is toggled via a compositor-level keybind (see Setting up a keybind below), not an in-app global hotkey — and this is deliberate, not a missing feature. Wayland's security model doesn't allow any client to listen for keypresses while it isn't focused; only the compositor itself has that privileged access, which is exactly why every Wayland compositor provides some way to bind a key to a command (a config file, or a GUI).

Routing through the compositor is the correct, secure way to do this — the alternative (a client reading raw kernel input events directly, bypassing Wayland's input model) means running with elevated device permissions and having the daemon read every keystroke on your system at all times just to catch one hotkey, which is a meaningfully bigger trust ask than this project wants to make for a screen-zoom tool.

Requirements

• A Wayland compositor implementing wlr-layer-shell-unstable-v1 and wlr-screencopy-unstable-v1
• wayland-client, wayland-protocols, wayland-scanner (pacman: wayland, wayland-protocols)
• EGL + OpenGL ES 2 development packages
• CMake ≥ 3.20, Ninja (optional)
• A C11 compiler

Compositor compatibility

Miru currently requires a compositor that exposes both wlr-layer-shell and wlr-screencopy.

• Niri — supported and used for development/testing
• Sway — supported; both required protocols are core to the wlroots ecosystem Sway is built on
• Hyprland — supported by the required wlroots protocols
• Mango — supported if the required protocols are exposed
• Nauka — supported and tested by @shadowash8 (https://github.com/shadowash8/nauka)
• SomeWM - supported and tested by @yvnth [https://somewm.org/]
• GNOME / Mutter — not supported
• KDE Plasma / KWin — not supported

Support for compositors without these protocols may be added later through alternative capture and overlay mechanisms.

Installing

Arch Linux (AUR)

# latest tagged release
paru -S miru-zoom
# or track the latest commit on main
paru -S miru-zoom-git

Substitute your AUR helper of choice — yay, paru, or a manual makepkg -si against the PKGBUILD.

Nix / NixOS

Miru is packaged in nixpkgs (attribute miru). Prefer that over the project flake when you want a normal channel/package install.

Note

The nixpkgs package is maintained by @yvnth — thank you! Releases in nixpkgs can lag behind upstream (Codeberg/GitHub tags). For the absolute latest commit, build from source or use the development flake below.

Run without installing (unstable channel):

nix shell nixpkgs/nixos-unstable#miru -c miru-daemon
# control client from the same package:
nix shell nixpkgs/nixos-unstable#miru -c miructl toggle

Classic nix-shell:

nix-shell -p miru -I nixpkgs=channel:nixos-unstable --run miru-daemon

Install to your user profile:

nix profile install nixpkgs/nixos-unstable#miru
# or: nix-env -iA nixpkgs.miru -f channel:nixos-unstable

NixOS — if your system follows unstable:

environment.systemPackages = with pkgs; [
  miru
];

On stable, pull only this package from unstable:

{ config, pkgs, ... }:
let
  unstable = import <nixos-unstable> { config = config.nixpkgs.config; };
in
{
  environment.systemPackages = [ unstable.miru ];
}

sudo nix-channel --add https://nixos.org/channels/nixos-unstable nixos-unstable
sudo nix-channel --update

Development / bleeding edge (optional project flake):

nix run git+https://codeberg.org/Vaishnav-Sabari-Girish/miru
nix develop git+https://codeberg.org/Vaishnav-Sabari-Girish/miru

Homebrew (Linuxbrew)

brew tap Vaishnav-Sabari-Girish/tap
brew install miru

From source

See Building below.

Building

# Using Ninja
cmake -S . -B build -G Ninja -DCMAKE_EXPORT_COMPILE_COMMANDS=ON
# Using Make
cmake -S . -B build -G "Unix Makefiles" -DCMAKE_EXPORT_COMPILE_COMMANDS=ON

Then run:

cmake --build build

Or with Grimoire:

grim cast build # Uses make to build by default

This builds two binaries: miru-daemon (the actual Wayland client) and miructl (a tiny, Wayland-independent socket client used to control it).

Installing the built binaries

To install miru-daemon and miructl to ~/.local/bin:

cmake --install build

Or with Grimoire, which also configures CMAKE_INSTALL_PREFIX for you:

grim cast install

Running

You can run miru-daemon directly in the foreground, or set it up as a systemd user service so it starts automatically with your graphical session.

Running directly

# Normal mode
./build/miru-daemon
# or
grim cast run-daemon

# Debug mode
MIRU_DEBUG=1 ./build/miru-daemon

As a systemd user service

Create ~/.config/systemd/user/miru.service:

[Unit]
Description=Miru Zooming Daemon
PartOf=graphical-session.target
After=graphical-session.target
ConditionEnvironment=WAYLAND_DISPLAY
ConditionPathExists=%h/.local/bin/miru-daemon

[Service]
ExecStart=%h/.local/bin/miru-daemon
Restart=on-failure
RestartSec=1

[Install]
WantedBy=graphical-session.target

This assumes miru-daemon has been installed to ~/.local/bin (see Installing the built binaries above) — adjust ExecStart/ConditionPathExists if yours lives elsewhere.

Then enable and start it:

systemctl --user enable --now miru.service

Either way, once running, miru-daemon connects to the compositor, logs every advertised protocol, opens a Unix socket at $XDG_RUNTIME_DIR/miru.sock, and then idles — no overlay is shown until told to toggle. Nothing else happens until a toggle command arrives (see Performance above for what that idling actually costs).

Toggle the overlay on/off:

./build/miru-daemon --version # prints version info + an ASCII logo, exits immediately
./build/miructl toggle        # freezes + zooms the screen / returns it to normal
./build/miructl loupe         # region loupe: drag a rectangle, then zoom that region only
./build/miructl spotlight     # standalone dim-around-cursor (click-through; cursor follow is a WIP)
./build/miructl quit          # tells the daemon to shut down

Man pages

miru-daemon and miructl each have their own man page. How you access them depends on how you installed Miru:

• Installed via miru-zoom-git (AUR), cmake --install build, or grim cast build/grim cast install — no extra step, man miru-daemon and man miructl work immediately.
• Homebrew — not wired up yet, coming soon.
• Built from source but not installed to $PATH — point man at the page directly from the repo root:

man ./miru-daemon.1
man ./miructl.1

Configuration

Miru uses a TOML configuration file located at:

$XDG_CONFIG_HOME/miru/config.toml

If XDG_CONFIG_HOME is not set, Miru follows the XDG fallback and uses:

$HOME/.config/miru/config.toml

The directory and default configuration file are created automatically on first launch.

The default configuration is:

[zoom]
factor = 2.0
increment = 0.25
max_factor = 10.0
smooth = false
upscale = "bicubic"

[spotlight]
radius = 250
dim = 0.65
softness = 20
animation_speed = 14.0
radius_step = 20.0

[general]
show_cursor = true

[annotate]
default = "rect"
thickness = 4.0
color = "ff3333"
text_color = "ffd933"
text_size = 1.0

[loupe]
shape = "rect"

The currently active options are:

• zoom.factor — initial zoom level applied on each toggle-on. Must be at least 1.0.
• zoom.increment — amount the zoom changes per key/scroll input. Must be greater than 0.
• zoom.max_factor — maximum zoom level. Must be at least 1.0.
• zoom.smooth — when true, zoom level and pan position are smoothly interpolated toward their targets instead of snapping.
• zoom.upscale - how the frozen capture is re-sampled when zoomed:
  • "nearest" - sharp, block (GL nearest)
  • "linear" - bilinear (default hardware filter)
  • "bicubic" - Catmull-Rom bicubic in the fragment shader (default)
• spotlight.radius — radius, in pixels, of the fully-bright circle around the cursor.
• spotlight.dim — how much darker the dimmed area gets, from 0.0 (no effect) to 1.0 (fully black).
• spotlight.softness — width, in pixels, of the feathered transition between the bright circle and the dimmed area.
• spotlight.animation_speed — how quickly Cursor Highlight radius/dim ease in and out when toggling Tab. Higher is faster.
• spotlight.radius_step — step size when adjusting the highlight radius with Shift+Plus/Minus or Ctrl+scroll.
• general.show_cursor — when false, hides the hardware cursor while the overlay is active (restoring a themed cursor when turning it back on may be limited depending on the compositor).
• annotate.default - default tool when entering annotate mode:
  • "arrow", "rect/rectangle", "line", "ellipse", or "text"
• annotate.thickness - stroke width for shapes (value ranges from 1 to 8)
• annotate.color - has RGB hex for shapes (default value is ff3333)
• annotate.text_color - has RGB hex for text (default value is ffd933)
• annotate.text_size - scale for annotation text (0.25 - 8.0; default is 1.0)
• loupe.shape - the shape to use when in loupe mode:
  • "rect"/"rectangle", "ellipse", "circle"

Invalid numeric values, including malformed, overflowing, non-finite, and non-positive values where applicable, fall back to safe defaults. zoom.factor is clamped to zoom.max_factor when necessary.

Note

[spotlight] values are live — they control the Cursor Highlight effect toggled with Tab while Magnifier mode is active. They're named [spotlight] in the config because they'll be shared with standalone Spotlight mode once that's built, not because Cursor Highlight and Spotlight mode are the same feature.

The config file is watched while miru-daemon is running — saving changes takes effect immediately, no restart needed. zoom.max_factor, zoom.smooth and every [spotlight] value update live, including on an already-active overlay; zoom.factor (the initial zoom on toggle-on) takes effect starting with the next toggle, since retroactively snapping an in-progress session to a different zoom level would be jarring rather than useful.

[annotate] changes apply to new strokes after reload (or the next toggle-on). Existing annotations keep the color/size they were drawn with.

Additional input, zoom and texture-upload diagnostics can be enabled by setting MIRU_DEBUG to a non-zero value:

MIRU_DEBUG=1 ./build/miru-daemon

Setting up a keybind

You'll want this bound to a key rather than run manually. Each supported compositor has its own way to bind a command to a key:

Note

Make sure miru-daemon is already running before triggering the keybind, or miructl will fail with a connection error.

Niri — ~/.config/niri/config.kdl:

Mod+Z hotkey-overlay-title="toggle miru" { spawn-sh "/path/to/miru/build/miructl toggle"; }
Mod+Alt+Z hotkey-overlay-title="toggle miru loupe" { spawn-sh "/path/to/miru/build/miructl loupe"; }

Hyprland — ~/.config/hypr/hyprland.lua:

hl.bind("SUPER + Z", hl.dsp.exec_cmd("/path/to/miru/build/miructl toggle"))
hl.bind("SUPER + ALT + Z", hl.dsp.exec_cmd("/path/to/miru/build/miructl loupe"))

Sway — ~/.config/sway/config:

bindsym $mod+z exec /path/to/miru/build/miructl toggle
bindsym $mod+alt+z exec /path/to/miru/build/miructl loupe

Mango — ~/.config/mango/config.conf:

bind=SUPER,Z,spawn,/path/to/miru/build/miructl toggle
bind=SUPER,ALT,Z,spawn,/path/to/miru/build/miructl loupe

Nauka — ~/.config/nauka/nauka.con:

keybind super z run "/path/to/miru/build/miructl toggle"
keybind super alt z run "/path/to/miru/build/miructl loupe"

SomeWM - ~/.config/somewm/rc.lua

awful.spawn.once("miru-daemon")
awful.key({ modkey }, "z", function()
  awful.spawn("/path/to/miru/build/miructl toggle")
end),

awful.key({ modkey, "Mod1" }, "z", function()
  awful.spawn("/path/to/miru/build/miructl loupe")
end),

Substitute the actual path to your built miructl binary in each case (or wherever it ends up if installed via a package manager).

On toggle-on, the daemon captures one frame via wlr-screencopy, uploads it as an OpenGL ES texture, and shows it in a fullscreen wlr-layer-shell overlay (correctly scaled on HiDPI outputs) at the configured zoom factor, centered on your cursor when possible. While active:

• Move the mouse to pan the zoomed view
• +/- or scroll wheel to adjust the zoom level
• Shift+Plus / Shift+Minus or Ctrl+scroll to adjust Cursor Highlight radius (while highlight is relevant / available)
• Arrow keys or WASD to pan by keyboard — press and hold for continuous panning at your keyboard's repeat rate
• Tab to toggle Cursor Highlight on/off — darkens everything except a soft-edged circle that follows the real pointer position across the screen (absolute tracking), using the [spotlight] config values. This is separate from the standalone Spotlight mode described above; see What it does for the distinction.
• Shift+A to toggle Annotate mode (orange frame, pan frozen):
  • W — arrow tool
  • R — rectangle tool
  • L — line tool
  • O — ellipse tool (Shift + drag for circle)
  • Left-click drag — place the current tool on the frozen frame
  • T - text tool
  • Click + type - start typing text from the clicked location (indicated by a _)
  • C — clear all annotations
  • Shift+A again — leave annotate mode (shapes remain until overlay exit or clear)
• Shift+H or ? — toggle the help panel (keybind cheat sheet). Esc closes help if it is open; otherwise Esc exits the magnifier.
• Esc, or pressing the toggle keybind again, to exit back to your normal desktop

There's deliberately no continuous re-capture of the underlying screen while the overlay is visible: an earlier version tried that and hit a feedback loop where the overlay could end up capturing itself (e.g. during Alt+Tab), so the frozen frame is captured once per toggle-on, matching boomer's actual freeze-on-demand behavior rather than a live feed. Zooming/panning/Cursor Highlight/annotations within that one frozen frame is fully live, however.

The overlay grabs keyboard and pointer input while active (needed for pan/zoom/Cursor Highlight/annotate to work), so clicks and most keys won't reach whatever's underneath until you exit; that's expected for Magnifier mode. A standalone Spotlight mode would behave differently — click-through by design, see What it does above.

Note

Cursor position on open: Wayland does not expose a global pointer position while Miru is inactive. The view starts at the last pointer position from a previous overlay session in the same daemon process when available; otherwise it may open near the center until the first pointer-enter/motion. Running miru-daemon as a long-lived service helps retain that last position across toggles, but does not track the cursor while the overlay is off.

Project structure

.
├── CMakeLists.txt
├── cmake/
│   └── WaylandScanner.cmake          # wraps wayland-scanner as CMake custom commands
├── protocol/                         # vendored protocol XML (not shipped by wayland-protocols)
│   ├── wlr-layer-shell-unstable-v1.xml
│   └── wlr-screencopy-unstable-v1.xml
├── src/
│   ├── main.c                        # daemon entrypoint, IPC-driven toggle loop
│   ├── wayland_state.h/.c            # connection, registry, seat/output tracking, poll-based event loop
│   ├── layer_surface.h/.c            # wlr-layer-shell overlay, zoom/pan, Cursor Highlight, GL draw
│   ├── annotations.h/.c              # shape annotation state (arrow/rect), screen↔buffer mapping
│   ├── help.h/.c                     # help panel copy (keybind list)
│   ├── font8x8_basic.h               # public-domain 8x8 bitmap font for the help panel
│   ├── capture.h/.c                  # one-shot screen capture via wlr-screencopy
│   ├── shm_buffer.h/.c               # shared-memory pixel buffer allocation helper
│   ├── egl_context.h/.c              # EGL display / context / window-surface setup
│   ├── gl_renderer.h/.c              # OpenGL ES 2 shaders, texture upload, spotlight, annotations, help
│   ├── ipc_server.h/.c               # Unix socket server, parses toggle/loupe/quit commands
│   ├── input.h/.c                    # pointer/keyboard: pan, zoom, Tab, annotate, help, key-repeat, Esc
│   ├── config.h/.c                   # config discovery, defaults, validation and loading
│   ├── config_watch.h/.c             # inotify-based watch on the config directory, drives hot-reload
│   ├── toml.h/.c                     # minimal TOML parser used by the config loader
│   ├── version.h.in                  # CMake-configured version string (git describe)
│   ├── logo.h                        # ASCII logo module interface
│   └── logo.c                        # ASCII logo data and printing implementation
├── ctl/
│   └── miructl.c                     # thin socket client, no Wayland dependency
└── Grimoire.toml                     # dev task runner (build/run/install/clean)

Roadmap

• Wayland connection, registry discovery, manual poll-based event loop
• Fullscreen wlr-layer-shell overlay surface
• Screen capture via wlr-screencopy
• Render the captured frame into the overlay (OpenGL ES + EGL, scale-aware)
• miructl control client + Unix socket IPC, daemon/client split
• Keybind-driven toggle: capture + show on activate, tear down on deactivate, no continuous re-capture while visible
• Magnifier mode: cursor-centered zoom + live pan, mouse/keyboard/WASD/ scroll zoom controls, proper multi-key repeat
• TOML configuration with XDG config directory support and configurable zoom/spotlight behavior
• Cursor Highlight (Tab): darken + feathered cursor cutout that follows the real pointer position (absolute tracking) even while zoomed
• Animated Cursor Highlight entry/exit; live radius adjust (Shift+/- / Ctrl+scroll); animation_speed / radius_step config
• Shape annotations on the frozen frame (Shift+A: arrow / rectangle / line / ellipse / circle)
• In-overlay help panel (Shift+H / ?)
• systemd user service + cmake --install/grim cast install support
• Hot-reloading of the config while miru-daemon is running
• man pages for miru-daemon and miructl
• Optional smooth interpolation for zoom/pan (zoom.smooth)
• Text annotations (typed labels on the frozen frame)
• Loupe mode (miructl loupe): region select, fixed-size window, cursor follow, content zoom inside the selection. Shape is configurable.
• Frame refresh
• Configurable capture upscale (zoom.upscale linear/nearest/bicubic)
• Export current view to an image making it easier to share to others or add to presentations (Check out test_export.bmp)
• Configurable annotation defaults ([annotate] in config.toml)
• 🚧 Spotlight mode: standalone, click-through overlay (no Magnifier freeze, works alongside normal desktop use)
• Cursor tracking for Spotlight mode without stealing input (likely Niri IPC or similar)
• Multi-monitor support
• Support compositors without wlr-screencopy / wlr-layer-shell

Similar tools

1. woomer — boomer for Wayland, written in Rust (uses raylib)
2. hyprmagnifier — a wlroots-compatible Wayland magnifier that does not suck
3. cboomer — a port of boomer written in C
4. cboomer (DavidBalishyan) — a different port of boomer, also written in C
5. zoomer — a port of boomer written in Zig, with Wayland support and an X11 fallback

License

See LICENSE.

Contributing

See CONTRIBUTING.md

🧠 (mostly) Brain made

This project was NOT vibe-coded BUT AI is still involved in some parts of it.

• Micro-improvements: I have used AI as an advisor to improve some bits of code here and there. Big refactors or new features are done by my hand though.
